OUR SERVICES

BASIC ENGINEERING

  • Inputs for Obtaining Environmental clearance.
  • Project feasibility report with economics for financial Institutes.
  • Technology evaluation and process Block diagram preparation.
  • Sizing of Equipment based on plant proposed capacity and future requirement.
  • Tentative Utility design and technology evaluation for treatment plant
  • Preparation of proposed equipment list with Specs & Budgetary cost.
    Preparing dimensional floor wise layout of plant building within and outside battery limits to freeze the footprints.
  • Submission of floor wise load calculations as an input to structural designer.
  • Preliminary Effluent characterization and treat ability studies
Design-and-Detailed-Engineering_1285x600

DETAIL ENGINEERING

  • According to capacity of plant dimension, Specification and MOC of equipment and Preparing Comprehensive list for the same.
  • GA drawings of reactor in AutoCAD
  • Floor wise GA Drawing of plant & utility.
  • 3D design of plant
  • Development of P&ID and Utility line diagram
  • Imposing GA drawings of suppliers in our proposed layout to check suitability.
  • Elevation drawing preparation.
  • Mass balance of various effluents streams and proposing treatment methodology.
  • Agitator power requirement calculations & Transformer ratings
  • Preparing BOQ for Pipelines & Electricals.(GA & SLD)
  • Development of Process data sheets for process equipment (PDS) which includes Agitator, pumps, valves, Reactors, column etc.
  • Piping layout Isometric views.
  • Design of Fuel handling & Material Handling systems.

EXECUTION

  • Co-ordination with Structural Engineer.
  • Checking foundations with respect to Drawings through total station.
  • Assistance in evaluation of quotations and bidding process.
  • Co-ordination with Civil, Mechanical, Electrical & Pipeline Contractors (MEP).
  • Hydro test & Working test before delivery.
  • Assistance in Erection & Plant commissioning.
